Command Types Command Codes Functions
System Command
/*Type; Acquires the models information.
/+xxxxxxxx; Rewrites the passwords: must be 8 digits.
/%Lock; Locks the keyboard.
/%Unlock; Unlocks the keyboard.
/:BellOff; Turn off the buzzer.
/:BellOn; Turn on the buzzer.
/^Version; Acquires the version of software
[x]All. Transfer signals from input channel [x] to all output
channels. Ex. Input 1 to all outputs = “1All.”
Operation Command
All# Transfer all input signals to matching output channels.
All$ Switch off all output channels.
[x]# Transfer signals from input channel [x] to output
channel [x].
[x]$ [x]$. Switch off output channel [x].
[x]V[x]. Transfer the video signals from input channel [x] to
output channel [x].
[x]V[x],[x],[x]. Transfer the video signals from input channel [x] to
output channels [x], [x] and [x]. Ex. “2V3,4,6.”
[x]A[x]. Transfer the audio signals from input channel [x] to
output channel [x]. Ex. Input1 to Output4 = “1A4.”
[x]A[x],[x],[x]. Transfer the audio signals from input channel [x] to
output channels [x], [x] and [x].
[x]B[x]. Transfer both video and audio signals from input
channel [x] to output channel [x]. Ex. “3B4.”
[x]B[x],[x],[x]. Transfer both video and audio signals from input
channel [x] to output channels [x], [x] and [x].
[x]P[x]. Transfer signals from input channel [x] to all output
channels in group [x].
[x]PP[x],[x],[x]. Group output channels [x], [x] and [x] under group
[x]. Ex. Outputs 3,7,9 saved as group 2 = “2PP3,7,9.”
S[x]. Acquires the output channels in Group[x].
Status[x]. Acquires the input channel to the output channel [x].
Status. Acquires the input channel to the output channels one
by one.
Save[Y]. Save the present operation to the preset command [Y].
[Y] ranges from 0 to 9. Ex. Preset 3 = “Save3.”
Recall[Y]. Recall the preset command [Y].
Clear[Y]. Clear the preset command [Y].
[X]*[X]! Transfer both video and audio signals from input
channel [x] to output channel [x].
