2.0 Introduction
The VGA series switcher is a high-performance professional computer and audio signal switcher that
can be used for cross switching multiple computer and audio signals. The VGA series switcher mostly ap-
ply in broadcasting TV engineering, multi-media meeting room, big screen display engineering, television
education, command control center or for other like applications. It provides power-fail locale protection
function, LCD displaying, shortcut selecting and saving function. With RS232 interface, it can be controlled
with PC, remote control system and any other 3rd party control systems. This user manual takes VGA0808
as the example; other models can take reference from it too.
Specifications Model
Video Inputs
Video Output
RS232 Interface
Audio I/O
MATRIX VGA0801
8
1
√
×
MATRIX VGA1601
16
1
√
×
MATRIX VGA3201
32
1
√
×
MATRIX VGA0404-A
4
4
√
√
MATRIX VGA0802
8
2
√
×
MATRIX VGA0802-A
8
2
√
√
MATRIX VGA0804 8
4
√
×
MATRIX VGA0804-A
8
4
√
√
MATRIX VGA0808
8
8
√
×
MATRIX VGA0808-A
8
8
√
√
MATRIX VGA1604 16
4
√
×
MATRIX VGA1604-A
16
4
√
√
MATRIX VGA1608
16
8
√
×
MATRIX VGA1608-A
16
8
√
√
2.1 Installation
The VGA Switchers can be easily rack mounted using the rack mount ears located in the front of the
unit. Secure the Switch with standard rack-hole screws. It is recommended to leave a 1U space be-
tween the units to have easy access for installation of the cables. When connecting the cables make
sure all cables are connected correctly if not it could cause color loss or will not output a display signal.
Packaging Includes
•
VGA Matrix Switcher
•
RS-232 Communication Cord
•
Power Supply Cord
•
CD with Application SWITCHER 2.0
•
User Manual and Quality Guarantee
•
Remote Control
