User’s Manual ACCESS SYSTEM
KLING & FREITAG GMBH ©1995-2009 Version 6.0, 17.03.2009 Page 15 of 60
4.2 B5 Subwoofer System, Specifications
4.2.1 B5 Applications
The ACCESS B5 is a high-performance subwoofer system of the ACCESS Series. It is
fully compatible with all existing Kling & Freitag speaker products and shows off all its
qualities here too. Because of its high efficiency and technical perfection, the B5 is used
in the high quality service segment, at discotheques and live sound coverage as well as
venues with fixed installations such as theatres and multimedia facilities. When used in
arrays with the optimally matched top speakers T5 and T9, the possibilities of use ex-
pand to include large events and mega open airs. The T9 meets all demands at the hig-
hest level --- from hard rock to classic.
4.2.2 B5 Technical Specifications
Design 3 chamber band pass, 6
th
order
Frequency response -10 dB 34 Hz - 400 Hz
Frequency response ± 3 dB 45 Hz - 190 Hz
Crossover frequencies max. 180 Hz, 130 Hz with controller C5/9
Nominal power handling 1200 W
Sensitivity 1 W/1 m 101 dB (45 Hz - 200 Hz)
Max SPL 136 dB (SPL peak/1 m)
Components 18" long excursion transducers (2)
Impedance 1 x 4
Ω
With option 'EP-5 instead of Speakon': 2 x 8
Ω
Connectors Sp.1: 2- / 3+-, Sp.2: 1- / 4+
Enclosure Trapezoid with 2 cluster angles 4°/15°
15 mm birch plywood with highly resistant
black structured paint
4 ergonomic butterfly handles
4 100 mm transport castors mounted on the rear,
ball proof front grille with exchangeable black
acoustic foam
Rigging 2 MAN CF4T flying points, 2 MAN HWKB strap
attachments for securing straps
Dimensions 600 x 900 x 750 mm without castors (W x H x D)
Weight incl. castors 82 kg
Options Transport cover with butterfly catches,
special finish in RAL colours, All Weather /
Outdoor version
