Paxton Superchargers 5.2 Dodge Ram User Manual
Page 29
P/N: 4809625
©2003 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
25NOV03 v2.0 97-01 5.2/5.9 Dodge(4809625v2.0)
A-7
SCALE:
SIZE
DWG. NO.
D
SHEET
1
O
F
1
REV
.
DA
TE
APPROV
ALS
DRA
WN
ENGINEERING
R&D
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
DECIMALS:
.XX
±
.01
.XXX
±
.005
MA
TERIAL
FINISH
NONE
SEE P
A
R
TS LIST
DO NOT SCALE DRA
WING
WEIGHT
.6 LBS
1:1
1019341
A
FRACTIONS:
ANGLES:
±
1/16
±
1/2•
ASY
, S/C OIL SUPPL
Y HOSE
APPR.
G. COMPTON
9/11/00
DODGE DURANGO
A. PROCTOR
G. COMPTON
10/5/00
10/6/00
1300 BEACON PLACE OXNARD, CA 93033
TEL: (805) 604-1336 F
AX: (805) 604-1337
CAD GENERA
TED DRA
WING,
DO NOT MANUALL
Y UPDA
TE
L. KECK
10/6/00
DESCRIPTION
HOSE, OIL SST BRAID #4 x 40" LG w/#4-AN 90
°
& STR
T
FTG, STR
T #4AN MALE x 1/4 NPT MALE
FTG, ELBOW 90
°
#4 AN MALE x 1/4 NPT MALE
FTG, STREET TEE 1/4 NPT MODIFIED
PA
R
T
NO.
7U250-090-400
7P250-031
7P125-004
7PP250-034
ITEM NO.
1
2
3
4
QTY
.
1
1
1
1
3
1
2
4
TO CYLINDER HEAD
TO STOCK OIL
SENDER UNIT
TO S/C OIL JET
Dr
a
wing No
.
1019341 Asy
, S/C Oil Supply Hose
