Paxton Superchargers 5.2 Dodge Ram - Manual (Page 32)

P/N: 4809625
©2003 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
25NOV03 v2.0 97-01 5.2/5.9 Dodge(4809625v2.0)
A-10
SCALE:
SIZE
DWG. NO.
D
SHEET
1
O
F
1
REV
.
DA
TE
APPROV
ALS
DRA
WN
ENGINEERING R&D
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE:
DECIMALS:
.XX
± .01
.XXX
± .005
MA
TERIAL
FINISH
NONE
SEE P
A
R
TS LIST
DO NOT SCALE DRA
WING
WEIGHT
4.1
LBS
1:1.5
1019715
A
FRACTIONS:
ANGLES:
± 1/16 ± 1/2•
ASY
, CRANK PULLEY
APPR.
G. COMPTON
9/8/00
DODGE DURANGO
A. PROCTOR G. COMPTON
9/8/00 10/6/00
1300 BEACON PLACE OXNARD, CA 93033 TEL: (805) 604-1336 F
AX: (805) 604-1337
CAD GENERA
T
ED DRA
W
ING,
DO NOT MANUALL
Y UPDA
TE
L. KECK
10/6/00
NOTES: UNLESS OTHERWISE SPECIFIED
ITEM NO.
1 2 3 4 5
QTY
.
1 1 6 6 1
PA
R
T
NO.
4PCD018-011 4PCD017-011
7A312-401 7K312-001 2A048-630
DESCRIPTION PULLEY
, CRANK 6 GRV
SP
ACER, CRANK
SCREW
, 5/16-18 x 4.00 HXHD GR8
W
ASHER, 5/16 FL
T SST
BEL
T,
8 GRV MICRO-V
1
4
3
2
TO STOCK CRANK PULLEY
5
S/C
TENSION PULLEY
IDLER PULLEY
1
Dr
a
wing No
.
1019715 Asy
, Cr
ank Pulle
y
