MPEG channel info
List of services of the channel, with the bit
rate of each one and the icon that indicates
the type of service.
Select with
and
.
Selected channel
Change using
Once a service is selected, it will be displayed the
information for that service:
Video info
MPEG audio info
Change audio service using
14. Setup
Change main configuration settings:
- Language: English, Español.
- Units: dBµV, dBmV, dBm
- Quality profiles: Trunk, Tap, End Line,
Ground.
Different thresholds are available for different
testing locations.
- Plan: FCC STD, FCC RETURN, FCC IRC, FCC
HRC, FCC OFFAIR, CCIR, and customers plans
saved using Learning Plan.
- Audio Carrier: 4.5 MHz, 5.5 MHz, 6.0 MHz, 6.5
MHz.
- Test port Compensation: Off / 1 dB to 30 dB.
Automatic compensation of the measures for
ports with attenuation.
- Network:
Setup: Manual, Auto
IP.
When Setup Manual is selected, the user
must set the IP.
Gateway.
When Setup Manual is selected, the user
must set the gateway.
DNS.
When Setup Manual is selected, the user
must set the DNS.
- Time and Date:
Set current time (hour and minutes) and
date (day of the month, month and year).
