Table of Contents
E-Series | Table of Contents
E-Series User Manual
Sections
Introduction & Product Details
1.1 Overview 6
1.2 Predictive Software 7
1.3 E15 Spec Sheet 8
1.4 E12 Spec Sheet 9
1.5 E218 Spec Sheet 10
1.6 E219 Spec Sheet 11
1.7 Cardioid Subs 12
System Configuration
2.0 E-Rack Description 13
2.1 E-Rack Overview 14
2.2 Configuration Example 15
2.3 Wiring Diagrams 16
Rigging
3.0 The 4 Stack Dolly 18
3.1 Rigging Overview 19
3.2 Rear Rigging 24
3.3 Front Rigging 25
3.4 Rigging Sticker Legend 27
3.5 Setting Angles 28
3.6 Attaching the Rigging Frame 29
3.7 Consequent Arrays 31
3.8 Highly Curved Arrays 33
3.9 Lowering the Array 34
3.10 Rigging the E Sub 35
3.11 Attaching Tops to Subs 36
Ground Stacking
4.0 Ground Stacking Legs 38
Truck Pack
5.0 Possible Configurations 39
