9252000981 Rev J
Figure 7. Pickup and Timing Test Setup
Figure 8. Target Operational Test Setup
BE1-50/51B-219
8
9
1
2
TIME
INST
10
CURRENT
SOURCE
INPUT
STOP
TIMER
START
AMPS
TEST SET
P0057-19
R
AC or DC
Voltage
Source
(V)
1 A Target Current
R = V/1
Rwatts = 1*V
Testing
BE1-50/51B-219/-226
