User Manual
28
Copy: allow you copy all the setting of one channel to other ones.
Alarm Type Function
Video Loss
Sends alarm when DVR can’t receive video signal (such as camera damage, cable broken or
damaged or power supply malfunction).
Motion
Detection
When an object moves into motion detection area, alarm will be triggered. You can adjust
sensitivity level to suit the needs of your actual application environment.
I/O Status System can convert alarm signal triggered by external sensor into signal identified by system.
HDD loss
When Hard Drive is not detected (HDD damage, power supply malfunction), or HDD
auto-overwrite is off, and free space is not enough, an alarm will be triggered.
5.3.6 Device
5.3.6.1 HDD Set
Click [Main menu Device HDD] to enter into the interface shown as Picture 5-40.
When DVR is connected to a HDD, the system will automatically detect if HDD is normal or not;
If the cable connected to HDD is loosen or HDD is abnormal, HDD status will be shown as “No Disk”, or,
If HDD need to be formatted, status will be shown as “no format”, otherwise, the HDD status will be shown as
“Normal”
NO: indicate HDD no pre-seted by system.
Status:：It will be available only when HDD have been formatted.
Total Space – Total size of the hard drive currently installed.
Free Space – Total amount of free space available on the hard drive currently installed.
Useable Rec. Time – Free space currently available in hours.
Auto-overwrite – When set to ENABLE the DVR will record over the oldest files on the hard drive. The
DVR will always be able to record events as they happen, however, it does means that you’ll need to get
important events off the HDD before they’re overwritten; and if overwrite is set to DISABLE the DVR will stop
record once the DVR is full. Whilst you won’t lose old footage, you run the risk of missing new events as they
happen. Be sure you want to do this before selecting it.
HDD Format – Formatting the HDD will erase all data (i.e. footage) which is stored on it, and re-create the
FAT (file allocation table).
USB Format - If you have a USB flash drive connected to the DVR, you can format that, too. To do this,
click the [USB Format] button and click [OK].
Note: It is an important first step when configuring your DVR to make sure that the hard drive (HDD)
options are correctly set. So, strongly suggest that you do format the HDD before start the first record.
5.3.6.2 PTZ Set
Click [Main Menu Device PTZ] to enter into the below window shown as Picture 5-42
List 5-1
Picture 5-40 Picture 5-41
