19
2
Hardware Installation
1
ON
4
5
1
ON
4
5
VCC5_IN Power Select
JP9
1-2 On: 5VSB
(default)
JP9 is used to select the power of the COM Express connector.
6 4 2
5 3 1
6 4 2
5 3 1
6 4 2
5 3 1
3-4 On: 5V
5-6 On: NC
