51
2
Hardware Installation
COM Express Connectors
The COM Express connectors are used to interface the carrier board with a COM
Express board. Refer to the following pages for the pin functions of these connec-
tors.
1
ON
4
5
1
ON
4
5
COM Express
Connectors (Type 2)
