6. To finish the deleting the Preset Channel, press the
key again to re-
turn to the last selected normal channel.
6.9 SCANNING
The
HX300 allows the user to select the scan type from “Memory Scan” or
“Priority Scan”. “Memory Scan” scans the channels that were programmed
into Scan Memory and also channels stored in the Preset Channel (“P0” ~
“P9”). “Priority Scan” is similar to the “Memory Scan” scan, however it scans
the priority channel (channel 16) and dual watches to channels programmed
in memory scan and preset channel memory. When an incoming signal is
detected on one of the channels during scan, the radio will pause on that
channel, allowing you to listen to the incoming transmission.
6.9.1 PROGRAMMING SCAN MEMORY
1. Turn the transceiver off by press and holding the
key.
2. Hold down the
key, and then turn on the trans-
ceiver while still holding down the
key. “
” icon
will appear on top right of the display.
3. Press the
or
key to select desired channel to
be scanned, then press the
key. The “ ” icon ap-
pears on the display, which indicates the channel has
been selected to the scan channel.
4. Repeat step 3 for all desired channels to be programmed into scan mem-
ory.
5. To DELETE a channel from the scan memory, select the channel by
pressing the
or
key, then press the
key. The “ ” icon disap-
pears from the display.
6. When you have completed programming scan memory, turn the trans-
ceiver off and on by press and holding the
key.
6.9.2 SELECTING SCAN TYPE
1. Turn the transceiver off by press and holding the
key.
2. Hold down the key, and then turn on the transceiv-
er while still holding down the key.
3. “
” icon will appear on the display, indicating the
Menu (“Set”) Mode has been activated.
4. Press the key until “SC” is shown in the bottom
right of the display.
5. Press the
or
key to select “PS (Priority Scan)”
or “MS (Memory Scan)”. The factory default is “PS
(Priority Scan)”.
