Standard Horizon HX-300 - Manual (Page 32)

HX300 Page 32
7. MENU (“SET”) MODE
The HX300’s Menu Mode allows a number of the HX300 operating param-
eters to be custom-configured.
The Menu Mode is easy to activate and set, using the following procedure:
1. Turn the transceiver off by press and holding the key.
2. Hold down the key, and then turn on the transceiv-
er while still holding down the key.
3. After “ ” icon appears on the display let go of both
keys.
4. The key when pressed scrolls through each menu
item:
LP - Lamp mode,
bP - key beep,
SC - Scan Mode,
dt - Dual watch or Tri-Watch mode,
FL - Water Enabled Strobe Menu,
AL - Weather alert
5. Press the or key will change the selection of
the selected menu item.
6. Press the key to save the menu selection.
7. After completing your adjustment, turn the transceiver off and on by
press and holding the key.
LP (LAMP MODE)
Function: Selects the Lamp illumination method for the
LCD/Keypad.
Available Values: on / ky / oF
Default: kEY
on: Illuminates the LCD/Keypad continuously.
ky: Illuminates the LCD/Keypad for 5 seconds when any key is pressed.
oF: Turns off the backlight for the LCD and keys.
bP (BEEP)
Function: Enable/Disable the Keypad beeper.
Available Values: HI / Lo / oF
Default: HI
