6.2 WIRING CONFIGURATIONS
Combining all the grounding and input type possibilities provides us with the follow-
ing potential connection configurations. The combinations along with our recommen-
dations on usage are shown in the chart below.
Recommended
Differential Inputs
Already Isolated
Grounds
Acceptable
Single-ended Inputs
Already Isolated
Grounds
Unacceptable without
adding Isolation
Differential Inputs
Common Mode
Voltage > +/-10V
Unacceptable without
adding Isolation
Single-Ended Inputs
Common Mode
Voltage > +/- 10V
Recommended
Differential Inputs
Common Mode
Voltage < +/-10V
Not Recommended
Single-Ended Inputs
Common Mode
Voltage < +/-10V
Acceptable
Differential Inputs
Common Ground
Recommended
Single-Ended Inputs
Common Ground
OUR VIEW
INPUT
CONFIGURATION
GROUND
CATEGORY
