Crystal oscillator
Frequency
10MHz
Frequency accuracy
100ppm
11.4 DIGITAL INPUT/OUTPUT
Digital type
FPGA
Configuration
Two ports, four bits each. Programmable as 8 input / 8
output or 4 input / 4 output
Input low voltage
0.8V max
Input high voltage
2.0V min
Output low voltage (IOL = 4mA)
0.32V max
Output high voltage (IOH = -4mA)
3.86V min
Absolute maximum input voltage
-0.5V , +5.5V
Interrupts
Programmable: levels 2 - 15
Interrupt enable
Programmable
Interrupt sources
End-of-conversion, FIFO-half-full, external (Ext Int)
11.5 ENVIRONMENTAL
Operating temperature range
0 to 70°C
Storage temperature range
-40 to 100°C
Humidity
0 to 90% non-condensing
34
