Hotshot Gas Fireplace Insert
XG0511 - 150203
Maintenance
Replacing the Fans
1. Turn off gas and power to the fireplace.
2. Remove the door and set aside.
3. Remove the logs, place to the side carefully.
Figure 14.
4. Remove the 4 screws holding down the burner tray
Figure 14a.
5. Carefully slide the burner tray forward to remove. You may need to
disconnect the gas line to remove the burner.
6. Carefully put the burner tray to the side. Take care to not damage
the pilot wires.
Figure 14b.
Figure 14c.
7. Remove 10 screws holding down the fan cover access plate
Figure 14d.
8. Disconnect fan power. Remove the screws holding down fan
bracket.
9. Reverse steps to reinstall. Make sure to replace the flex line if you
disconnected the gas line. They are a one time use only.
Figure 14e.
