21
Amount of discharge adjustment setting
1. Press the SEL button several times to make the flash output
amount indicator blink.
2. Press the + button or – button to set the flash output amount.
3. Press the SEL button several times to make the display stop
blinking.
USING THE SIGNAL OF THE FLASH THAT IS ATTACHED TO THE CAMERA AS THE TRIGGER
It is possible to use the signal of EF-610 DG SUPER PA-PTTL flashgun that is attached to the camera
for triggering another EF-610 DG SUPER PA-PTTL apart from the camera.
◆ This only works with 2pcs or more EF-610 DG SUPER PA-PTTL flashguns.
◆ In this instruction, we call a flash unit, which is attached to the camera body the “Controller”, and we
call a flash unit at a remote position the “off-camera flash”.
When only OFF-CAMERA FLASH is triggered
Controller Setting
1. Attach the flash unit to the camera.
2. Press the MODE button to select the ⁄ TTL ⁄
⁄ mark.
3. Press SEL button, to make the channel indicator blink on the
display.
4. Press + or – button to set the desired channel number.
5. Press the SEL button several times until the display stops blinking.
Off-Camera Flash Setting
6. Press the MODE button to Select the ⁄ TTL ⁄ ⁄
mark.
7. Press SEL button, to make the channel indicator blink, on the display.
8. Press + or – button to choose the same channel number as
set on the controller.
9. Press the SEL button several times until the indicator stops blinking.
10. Place the off-camera flash at the desired position.
11. Check that both flashes are fully charged.
◆ Ready light lamp will light, and the AF Auxiliary lamp will blink to indicate that the flash is ready for
shooting.
12. Adjust the focus on the subject, and take the picture.
◆ It is also possible to use High Speed Synchro photography. After the above-mentioned setting
please set flash of controller as High Speed Synchro. Please refer to High Speed Synchro
photography section for more details.
When triggering both CONTROLLER and OFF-CAMERA FLASH.
Controller Setting
1. Attach the Flash to the camera.
2. Press the MODE button to select the ⁄ TTL ⁄
mark.
3. Press SEL button, to make the channel indicator blink on the display.
4. Press + or – button to set the desired channel number.
5. Press SEL button to make the indicator stop blinking.
Off-Camera Flash Setting
6. Press the MODE button to Select the ⁄ TTL ⁄ ⁄
mark.
7. Press SEL button, to make the channel indicator blink on the display.
8. Press + or – button to choose the same channel number as
on the controller.
9. Press the SEL button several times until blinking stops.
10. Place the off-camera flash at the desired position.
