TEATRO 80 - M80
The TEATRO 80 - M80 projector uses the maximum in
signal processing technology as well as the innovative
DLP™ and a refined optical system.
Its range of inputs (1 Composite Video inputs, 1 S-
Video inputs, 2 Component or RGB inputs (4 RCA
connectors and 5 BNC connectors), 2 graphic RGB
inputs, 6 HDMI™ inputs, 1 SDI input, 1 DVI-D input)
allow it to be connected to a wide range of analogue
and digital sources: DVD players, video recorders, sa-
tellite and terrestrial receivers, computers, video game
consoles, camcorders, etc.
Its image processing system permits optimum repro-
duction of a wide range of input signals, from interlaced
video to high definition and digital graphics.
Faithful reproduction of signals at higher resolutions
(such as high definition video and graphics) occurs
without loss of information or reduction of image sharp-
ness thanks to the processor’s high pixel rate signal
acquisition capabilities.
Different input signal resolutions can be adapted to
match the specified screen resolution without loss of
image quality, thanks to a generous selection of default
aspect ratios, some of which are user definable.
All picture adjustments can be made with the remote
control interacting with a simple menu-activated On
Screen Display; alternatively, the projector can be
controlled by a home automation system through its
serial port , the 1.1 USB port, an RS232 serial port or
the RJ45 Ethernet port.
The appliance has been subjected to exhau-
stive operating tests by SIM2 to guarantee the
highest quality.The projector bulb life should
thus initially be around 30-60 hours.In addition
to the customary checks, the Quality Control
department also runs additional statistical tests
before shipment.
In such cases, the packaging may show signs
of having been opened, and the hours of lamp
operation may prove to be higher than those
normally shown when only standard tests are
performed.
