10
Setting Up Your KMV-3901/3911 Multiviewer
Networking Setup
2 Press the [–] button repeatedly until RESTORE POINTS appears on the display, and then
press the SEL button.
3 Press the [–] button repeatedly until DEFAULT ACTION appears on the display, and then
press the SEL button.
• If the control panel’s display shows KEEP SETTINGS, then the controller
configuration will not prevent you from changing your KMV-3901/3911 card’s IP
address.
• If the control panel’s display shows UPDATE SETTINGS, navigate to KEEP SETTINGS
by pressing the [+] button, and then press the SEL button to apply your change.
4 Press the CONTROLLER button to exit the controller’s menu.
Changing the Multiviewer’s IP Address
To change the IP address of a KMV-3901/3911 multiviewer card
1 Press the Select button on the front edge of the KMV-3901/3911 card.
The Status LED on the selected card flashes orange, and the associated control menu
appears on the display of the Densité frame’s local control panel.
2 On the local control panel, press the [–] button repeatedly until NETWORK SETTINGS
appears on the display, and then press the SEL button:
Note:
You can navigate the control menu by using the four buttons located
beneath the display:
• Press the [+] and [–] buttons, to navigate between menu options or
between parameter values.
• Press SEL to access the next menu level. When a parameter value is shown
on the display, modify the value by using the [+] and [–] buttons, and then
press SEL to apply the new value.
• Press ESC to go back to the previous menu level.
• Once you have completed your changes, press the Select button on the
front edge of the KMV-3901/3911 card to exit the control menu.
Select button
Status LED
Boot LED,
Power LED,
CPU Status LED (other side of board)
SDI LEDs
USB connector (other side of board)
