142 Kayak HD — Installation and Service Manual
Section 3 — Configuration
Install - Tally Menu
The tally signalling for the Kayak works via serial communication line with
the option to hook a hardware device onto that (those) serial line(s) to
provide tally for those cases where it is not connected to a control system,
e.g. Jupiter from Grass Valley. For that optional hardware device the
already existing Tally Distributor MI-3040 was chosen. This device is
driven via the serial MPK protocol and has 40 opto-isolated inputs and 40
relay outputs. Because the maximum needed amount of inputs and outputs
is greater than 40 more then one (up to three) MI-3040 boxes are needed.
The menus serves for installing the Tally Distributors connected with the
Kayak HD. For installation details refer to your MI-3040 manual.
You can configure Tally outputs in the Kayak control panel software from
the
Config - GPO/Tally menu which is described in more detail in the separate
Kayak User Manual.
Figure 96. Install – UMD Setup Menu
