Kayak HD — Installation and Service Manual
Appendix C — Control Interfaces
ESAM Protocol
Starting with software version 6.9.4 the Kayak switcher supports the ESAM
protocol to connect to an audio mixer, e.g. Yamaha DM-1000.
Supported Commands
ESAM (Editing Suite Audio Mixer) protocol has been defined by Graham-
Patten Systems, Inc.
The full ESAM-2 (a.k.a. SERIAL-II) Protocol Specification can be down-
loaded from http://www.gpsys.com/products/protocols.htm.
The following commands of the ESAM-2 protocol are supported:
Table 25. Supported Commands
Command Type
Read Command
Write Command
All Stop
-
A0
From Source
-
A1
To Source
-
A3
Transition Start
-
A9
Fader Level
-
AD
Transition Duration
-
AF
