50
Kayak HD — Installation and Service Manual
Section 2 — Installation
Control Panel Installation
1 M/E Control Panel
Figure 25. Kayak HD 100C Control Panel Dimensions 1 of 2
8324_01_r2
418 mm
16.46 in.
398 mm
15.66 in.
10 mm
0.39 in.
34 mm
1.31 in.
16 mm
0.60 in.
11 mm
0.40 in.
66 mm
2.55 in.
81 mm
3.19 in.
260 mm
10.23 in.
145 mm
5.69 in.
Left side view
20°
7°
