Page 45
35
NV9648
User’s Guide
Button Functions for LCD XY/MD Mode
These are the button types available for NV9648 configurations under the LCD XY/MD model:
Quick Source A quick source button selects a source and performs an immediate take.
When you assign a quick source button, a drop-down menu appears in which
you choose a source device. (The ‘None’ entry is merely a placeholder. Do not
choose ‘None’.)
Salvo
Executes a salvo.
When you assign a Salvo button, a drop-down list appears in which you select a
system salvo (previously defined in NV9000-SE Utilities).
The ‘None’ entry is merely a placeholder. Do not choose ‘None’.
(You can cause the panel to generate salvo buttons automatically using the
options of the ‘Edit Navigation Button’ dialog when you create a navigation
button.) See
‘Edit Navigation Button’ Dialog
on page 39.
Source
A source button selects a source. (Note that a quick source button selects a
source and also performs an immediate take.)
When you assign a source button, a drop-down menu appears: ‘Source Device’.
Choose a device from the list. (The ‘None’ entry is merely a placeholder. Do not
choose ‘None’.)
Take
A ‘Take’ button performs the route set up by a destination selection and a source
selection.
Undefined
Makes the button undefined and inactive. On the actual panel, it will remain
unlit (dark).
Type
Description
Back
The ‘Back’ function places the predecessor of the current button page on the
panel.
The panel software can introduce a “back” button if an automatically generated
list has more entries than can fit on a page.
Category
Displays a category’s device list.
When you assign a category button, two additional drop-down menus appear:
‘Src Category’ and ‘Dst Category’. Choose a category from one of the category
lists. When you choose a source category, the destination categories become
inaccessible and vice versa: a category button must be either a source category
or a destination category. You must choose ‘None’ in either category list to
switch to the other category list.
When the operator clicks the category button, a list of devices in the category
appears.
The default button text will be the category name. You can override the default
text.
Type
Description
