188
M3 Cards
M3 Cable and Connectors
The M3 cable has identical connectors on each end. This is a drawing of the cable connector:
The connectors are keyed so that you cannot connect the cables in the wrong orientation.
In addition, the label is always on the same side. You can use the label to determine the
orientation in which you plug these cable heads into the connectors on the routers’ backplanes.
M
3
I
n
te
gr
a
tion
cable
MA
DE IN USA
3.172
[80.57]
Keyway
Keyway
