Audio board connector
23 July 2004
Profile XP System Guide
329
Audio board connector
The Audio Board accepts 16 channels of digital audio input and provides 16 channels of
digital audio output via a 80-pin connector on the rear panel. The cable to this connector
is from the Profile Audio Chassis (PAC) or from the XLR/BNC 216 Digital Audio
Breakout Box.
Female
0624-36
1
40
80
41
