6-MAINTENANCE AND CLEANING
ATTENTION!
All cleaning operations of all parts must be performed when the closed fireplace is completely cold.
CLEANING PERFORMED BY THE USER
CLEANING THE GLASS
The glass can be cleaned with specific products (see our price list), with a cloth soaked in a water and ammonia solution or a little white
ash and a sheet of newspaper.
To open the door (figure 15-16) to clean the glass, LOWER THE GLASS COMPLETELY and open the door as shown in the figure, using the
cold handle supplied. One does not need to block the door opening as, in the "Forma right/left" version, once the handle is lowered, this
blocks the sliding system, while in the “T50/T95” version, when one pulls the handle towards point B, this prevents the sliding opening.
To close repeat the stages described above in the reverse order.
DURING OPENING BUT ESPECIALLY CLOSING ACCOMPANY THE DOOR WITHOUT FORCING IT.
FOR EXAMPLE FORCING THE DOOR DOWNWARDS WHEN CLOSING COULD MAKE THE GLASS KNOCK AGAINST THE MANTEL AT THE
BOTTOM OF THE FIREPLACE, BREAKING IT.
ATTENTION!
Do not spray the product onto the painted parts or onto the door gaskets (ceramic fibre cord)
FIGURE 15 - FLAP DOOR OPENING / CLOSING (FORMA
DX-SX)
DETAIL OF HANDLE FOR FLAP DOOR OPENING (ABOVE FORMA
DX/SX - BELOW FORMA T95/T50)
A – CLOSED POSITION
B – OPEN POSITION
FIGURE 16 - FLAP DOOR OPENING FORMA T50/T95)
