Model PD6300 Pulse Input Rate/Totalizer Instruction Manual
92
Display Parameter Action/Setting Description
LatCH Latching Set relay for latching operation (relays as-
signed to rate)
LED t LED test Test all LEDs
Length Length Not applicable
Linear Linear Set meter for linear function and select
number of linearization points
Lit Hi Max on little
display Assign digital input to display max on the
small display
Lit HL Max/min little
display Assign the digital input to toggle max/min
on the small display
Lit Lo Min on little dis-
play Assign digital input to display min on the
small display
Little Little display To assign the small display parameters
locd Locked Enter password to unlock meter
Lt-CLr Latching-cleared Set relay for latching operation with manual
reset only after alarm condition has cleared
(relays assigned to rate)
nmAn Manual To manually control
nmAx Maximum Program maximum mA output allowed
mbus Modbus Select to display Modbus input or to assign
Modbus input as the analog output source
nmenu Menu button Assign digital input to Menu button
nmin Minimum Program minimum mA output allowed
No PtS Number of points Set meter for 2 to 32-point linearization
nonrst Non-resettable Non-resettable grand total set after entering
“050873” for Gtotal password
O Hold Relay output hold
OFF Off Disable relay and front panel status LED,
turn relays off, program off time delay
OFF 1 Off Disable relay and front panel status LED,
turn relays off, program off time delay
On On Enable fail-safe operation, turn relays on,
program on time delay
