Ind. LuNAR RK200DTG3 Installation Guide
2
General Description
The Industrial LuNAR DT AM Grade 3 (RK200DTG3) is a dual technology ceiling detector with a
mounting height of up to 8.6m (28ft) that incorporates RISCO Group’s Anti-Cloak™ Technology (ACT™).
The detector has an Intelligent Digital Signal Processing method that automatically adjusts the alarm
threshold and pulse count verification according to actual intruder crossing speed and environmental
factors, providing superior detection and false alarm immunity.
The Ind. LuNAR RK200DTG3 can operate as a regular relay detector connected to any control panel, or
as an addressable BUS detector when connected to RISCO Group’s ProSYS control panel via the RS485
BUS.
Ind. LuNAR RK200DTG3 Features
♦
PD6662, EN50131-1, EN50131-2-4 Grade 3
♦
Addressable Dual Technology detector with Anti-Cloak™ Technology
♦
Up to 8.6 m (28ft) mounting height
♦
360
0
by 18m (60ft) diameter coverage pattern
♦
3 independent PIR channels for customized coverage
♦
Intelligent Digital Signal Processing – alarm verification and decision thresholds adjusted
according to actual intruder crossing speed
♦
Built-in Triple EOL resistors, jumper selectable
♦
Active IR for Anti-Masking meeting EN50131 requirements
♦
Ceiling and cover tampers
♦
"Green Line" setting – for disabling the MW when the premises are occupied
♦
Opto–relays for low current consumption and long life
♦
Remote and Local Self Test
♦
Remote SET input
♦
Remote RC control input
♦
PIR coverage optimization by sliding the lenses
♦
Microwave Range Adjustment manually (analog trimmer) and remotely (digital setting)
♦
Trouble Indication (by LEDs or via communication)
♦
3 Triple color LEDs for easy walk testing
♦
Advanced Remote control and diagnostics
♦
Reduced Power Consumption when connected to RISCO Group’s ProSYS
