PKV101
Service
- 21 -
20. Remove the four bolts that hold the back plate to the
engine.
19. If it becomes necessary to remove the frame and back
plate from the engine for engine service remove the
two bolts that hold the frame to the bottom of
back
plate.
18. Inspect both halfs of the seals for imperfections and
replace as necessary.
17. Carefully pry the stationary seal outward, using two
screwdrivers if necessary. Note: if the seal is stuck in
casing it may become necessary to squirt a small
amount of liquid soap and water on sealing surface to
loosen seal . It also may become necessary to re-
move the back plate to push the seal out when
prying from the front does not work.
