Semi Trash Pumps - PKX
Service
- 66 -
21. Lift the back plate out of the way and inspect for
damage. This is also the way to remove the seal if it
is stuck in backplate.
23. Behind the pump backplate is a smaller engine
adapter plate that will need to be reomved if engine
work is necessary. It will pop off with a soft rubber
mallet if stuck on.
24. The engine is held on with four bolts. Loosen the f
our bolts and remove from frame if engine work is
needed.
22. If the seal still does not come out, it may become
necessary to push on the back of the seal with a
screwdriver to remove from its position.
