SAF-HOLLAND XL-PH10412UM PH-995 Pin and Clevis Coupler User Manual

Page 2

Advertising
background image

2

XL-PH10412UM-en-US Rev A · 2011-10-28 · Amendments and errors reserved. © SAF-HOLLAND, Inc.

Contents

Contents Page

Introduction ..............................................2
Warranty ...................................................2
Notes, Cautions, and Warnings ..................2
Important Safety Instructions ....................3
Exploded View ..........................................4
Parts List ..................................................5
Dimensions ...............................................5
Section 1 – Drawbar Eye Dimensions.........6
Section 2 – Load Ratings ...........................6

Contents Page

Section 3 – Towing Applications ................6
Section 4 – Installation Options ................7
Section 5 – PH-995SH71 Complete Assembly

Mounting Instructions .............8

Section 6 – Retrofit of PH-775-01552

Mounting Instructions ........... 10

Section 7 – Operating Instructions .......... 14
Section 8 – Maintenance ......................... 16
Section 9 – Rebuild Kits .......................... 17

Introduction

This manual provides information necessary
for the proper mounting, operation, maintenance,
and inspection of the SAF HOLLAND coupler.

NOTE: For Holland replacement

components contact
SAF-HOLLAND Customer
Service: 888-396-6501.

Warranty

This product is covered by SAF-HOLLAND’s
Coupling Products Commercial Warranty. Refer
to the complete warranty for the country in
which the product will be used. A copy of the
written warranty can be downloaded from our
SAF-HOLLAND website (www.safholland.us).

Notes, Cautions, and Warnings

You must read and understand all of the
procedures presented in this manual before
starting any work on the pintle hook.

NOTE: In the United States, work shop

safety requirements are defined by
federal and/or state Occupational
Safety and Health Act. Equivalent
laws may exist in other countries.
This manual is written based on
the assumption that OSHA or other
applicable employee safety
regulations are followed by the
location where work is performed.

Proper tools must be used to perform the
mounting and maintenance procedures
described in this manual.

Throughout this manual, you will notice the
terms “NOTE”, “IMPORTANT”, “CAUTION”, and
“WARNING” followed by important product
information. So that you may better understand
the manual, those terms are as follows:

NOTE: Includes additional information

to enable accurate and easy
performance of procedures.

IMPORTANT: Includes

additional

information that if
not followed could
lead to hindered
product performance.

Used without the safety alert
symbol, indicates a potentially
hazardous situation which,
if not avoided, could result
in property damage.

Indicates a potentially
hazardous situation which,
if not avoided, could result
in minor or moderate injury.

Indicates a potentially
hazardous situation which,
if not avoided, could result
in death or serious injury.
