GETTING READY
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
12
LCD (liquid crystal display) operation
Selected stitch, pattern settings and messages are displayed on the LCD (liquid crystal display) on the front
of the sewing machine.
Viewing the LCD
When the power is turned on, the LCD comes on, and the following screen is displayed.
The LCD display is changed using the
keys on the right, and operations
performed by directly touching the LCD.
If it is difficult to press the buttons on the LCD by hand, you can use the touch pen to operate the LCD display.
■ Utility stitch selection screen
a Selected stitch
b Presser foot to be used
c Stitches
d Stitch width (mm)
e Stitch length (mm)
f Automatic reverse/reinforcement
g Automatic thread cutting
h Horizontal mirror image key
i Number of stitches in group
j Number of the selected stitch
k Increase value
l Decrease value
Memo
z A different screen is displayed when the embroidery unit is attached.
z Refer to "Error messages" (page 153) for messages displayed on the LCD.
z Depending on the model of sewing machine, an animation may be displayed when the power is turned
on. When an animation is displayed, the screen above will be displayed if you touch the LCD with
your finger.
2
1
5
4
6
7
9
0
8
A
B
3
