STaNDaRD flEXIblE hD CablES
Cable
group
Cable p/n
Cable type
1 GHz
(VHF/UHF)
dB/m dB/ft
2 GHz
(band L)
dB/m dB/ft
3 GHz
(band S)
dB/m dB/ft
4.5 GHz
(band C)
dB/m dB/ft
8 GHz
(band C)
dB/m dB/ft
12.4 GHz
(band X)
dB/m dB/ft
18 GHz
(band Ku)
dB/m dB/ft
4.6/75 D
C291 333 039
HD 0.6/2.8
mini RG59 type
0.34/0.10
0.50/0.15
0.62/0.19
6/75 D
C291 360 093
HD 0.8/3.7
RG59 type
0.25/0.07
0.35/0.11
0.44/0.13
0.54/0.16
7/75 D
C291 384 083
HD 1.0/4.8
RG6 type
0.19/0.06
0.28/0.08
0.35/0.11
0.44/0.13
CORRUgaTED CablES
(spiral outer shielding)
Cable
group
Cable p/n
Cable type
2 GHz
(band L)
dB/m dB/ft
3 GHz
(band S)
dB/m dB/ft
6 GHz
(band C)
dB/m dB/ft
8 GHz
(band C)
dB/m dB/ft
12.4 GHz
(band X)
dB/m dB/ft
18 GHz
(band Ku)
dB/m dB/ft
20 GHz
(band Ku)
dB/m dB/ft
Celiflex 1/4"
C291 993 170
HCF 1/4"-50 AlCu
0.27/0.08
0.34/0.10
0.51/0.15
0.60/0.18
0.78/0.24
0.99/0.30
1.06/0.32
Celiflex 3/8"
C291 996 170
HCF 3/8" CuH-50 AlCu
0.19/0.06
0.24/0.07
0.36/0.11
0.43/0.13
0.54(11.7)/
0.16(11.7)
Celiflex 1/2"
C291 994 170
HCF 1/2" CuH-50 AlCu
0.16/0.05
0.20/0.06
0.30/0.09
0.36/0.11
0.42(10)/
0.13(11.7)
(11.7) = 11.7 GHz
(10) = 10 GHz
haND-fORmablE aND SEmI-RIgID CablES
Cable
group
Cable p/n
Cable type
2 GHz
(band L)
dB/m dB/ft
3 GHz
(band S)
dB/m dB/ft
6 GHz
(band C)
dB/m dB/ft
8 GHz
(band C)
dB/m dB/ft
12.4 GHz
(band X)
dB/m dB/ft
18 GHz
(band Ku)
dB/m dB/ft
20 GHz
(band Ku)
dB/m dB/ft
.047"
C291 855 001
SR copper
1.64/0.50
2.03/0.61
2.93/0.89
3.43/1.04
4.73/1.32
5.39/1.63
5.72/1.73
C291 855 065
SR tinned copper
1.64/0.50
2.03/0.61
2.93/0.89
3.43/1.04
4.73/1.32
5.39/1.63
5.72/1.73
.085"
C291 844 065
Handformable
unjacketed
0.97/0.29
1.21/0.37
1.78/0.54
2.10/0.64
2.71/0.82
3.39/1.03
3.62/1.10
C291 850 001
SR RG405/KS1
0.94/0.29
1.18/0.36
1.73/0.53
2.05/0.62
2.64/0.80
3.31/1.00
3.53/1.07
C291 850 005
SR tinned copper
0.94/0.29
1.18/0.36
1.73/0.53
2.05/0.62
2.64/0.80
3.31/1.00
3.53/1.07
C291 851 001
SR non magnetic
0.94/0.29
1.18/0.36
1.73/0.53
2.05/0.62
2.64/0.80
3.31/1.00
3.53/1.07
C291 844 187
SR aluminium
0.98/0.30
1.22/0.37
1.80/0.54
2.12/0.64
2.73/0.83
3.41/1.03
3.64/1.10
.141"
C291 864 065
Handformable
unjacketed
0.57/0.17
0.72/0.22
1.09/0.33
1.30/0.39
1.71/0.52
2.18/0.66
2.34/0.71
C291 866 378
Handformable
FEP jacketed
0.63/0.19
0.80/0.24
1.20/0.36
1.42/0.43
1.87/0.57
2.37/0.72
2.54/0.77
C291 860 001
SR RG402/KS2
0.50/0.15
0.64/0.19
0.97/0.30
1.17/0.35
1.55/0.47
1.99/0.06
2.14/0.65
C291 862 005
SR tinned copper
0.50/0.15
0.64/0.19
0.97/0.30
1.17/0.35
1.55/0.47
1.99/0.06
2.14/0.65
C291 861 066
SR silvered copper
0.50/0.15
0.64/0.19
0.97/0.30
1.17/0.35
1.55/0.47
1.99/0.06
2.14/0.65
C291 861 061
SR non magnetic
0.50/0.15
0.64/0.19
0.97/0.30
1.17/0.35
1.55/0.47
1.99/0.60
2.14/0.65
C291 864 187
SR aluminium
0.53/0.16
0.67/0.20
1.02/0.31
1.23/0.37
1.62/0.49
2.08/0.63
2.23/0.38
.250"
C291 870 001
SR RG401/KS3
0.31/0.09
0.41/0.12
0.64/0.20
0.79/0.24
1.08/0.33
1.42/0.43
1.54/0.47
C291 874 187
SR aluminium
0.33/0.10
0.43/0.13
0.68/0.21
0.83/0.25
1.13/0.34
1.48/0.45
1.60/0.49
