7-1
7.1 Messages
7 Operation
7 7000 Operation Operation 7- 7.1 Messages 7100 Messages 7- Betrieb_Meldungen_allgemein_BA
When the supply voltage is switched on, the PNOZmulti safety system
copies the configuration from the chip card.
The LEDs "POWER","DIAG", "FAULT", "IFAULT" and "OFAULT" light up
on the base unit.
Betrieb_Meldungen_Feldbus_sercos III
The expansion module PNOZ mc10p is configured and started auto-
matically. The LED "S3" displays the status of PNOZ mc10p at sercos
III.
7.1.1 Display elements for device diagnostics
Display elements for device diagnostics 7- Anzeige Legende 3x
Legend:
Betrieb_Anzeige_Feldbus_SercosIII_BA
LED on
LED flashes
LED off
LED Meaning
PWR Supply voltage is present
Supply voltage is not present
LINK ACT1 Green Bus connection available at X1
Green Data traffic present at X1
Bus connection is not available at X1
LINK ACT2 Green Bus connection available at X2
Green Data traffic present at X2
Bus connection not available at X2
