2 Getting Started
The following items are needed:
• a 12 - 70 Volt DC power supply, see the section below entitled “Choosing a Power Supply” for
help in choosing the right one
• a small flat blade screwdriver for tightening the connectors (included)
• a PC running Microsoft Windows XP, Vista, or Windows 7 or 8
• an Applied Motion Products programming cable for RS-232 interface and another cable for
CANopen daisy-chain(both included with TSM23C, CANopen converters are available from
Applied Motion Products)
2.1 Installing Software
Before utilizing the TSM23C Integrated Step-Servo Motor and Step-Servo Quick Tuner Software in
an application, the following steps are necessary:
• Install the Step-Servo Quick Tuner software from the Applied Motion Products website.
• Connect the drive to the PC using the programming cable.
• Connect the drive to the power supply. See instructions below.
• Launch the software by clicking Start...Programs...Applied Motion Products.
• Apply power to the drive.
• The software will recognize the drive and display the model and firmware version. At this point,
it is ready for use.
2.2 Mounting the Hardware
As with any step motor, the TSM23C must be mounted so as to provide maximum heat sinking
and airflow. Keep enough space around the Integrated Motor to allow for airflow.
• Never use the drive where there is no airflow or where other devices cause the
surrounding air to be more than 40°C (104°F).
• Never put the drive where it can get wet.
• Never use the drive where metal or other electrically conductive particles can
infiltrate the drive.
• Always provide airflow around the drive.
