MicroQ
APANTAC LLC, 7556 SW BRIDGEPORT ROAD, PORTLAND, OR 97224
, TEL: +1 503 968 3000, FAX: +1 503 389 7921
8
4.3.2
The MicroQ can be mounted 3 different ways
• Using the standard magnetic mounting plate
• Using the optiona VESA plate for mounting on the back of the monitors
• Using the optional rack mount to mount 2 MicroQ’s side by side
Figure 4-4: MicroQ Standard Mounting Plate
Figure 4-5: MicroQ Optional Vesa Mounting Plate
