KST-12000 Ku-Band Satellite Terminal

Revision 4

Single-Thread System Installation

MN/KST12000.IOM

2.5.1 TX/IF Input (J1)

The TX/IF input is a TNC type connector that comes from the indoor unit. The input
impedance is 50

, and the frequency is 70 MHz,

±

18 MHz. The typical power level is

from -43 to -19 dBm, depending on the customer’s configuration and application.

2.5.2 TX/RF Output (J2)

The TX/RF output is a WR-75 G interface with an output impedance of 50

. The output

frequency range is 14.0 to 14.5 GHz. The output power level is dependent on the power
amplifier ordered in the system.

2.5.3 RX/IF Output (J3)

The RX/IF output is a TNC type connector that sends the received signal to the indoor
unit. The output impedance is 50

, and the frequency is 70 MHz,

±

18 MHz.


The 1 dB output compression point is +17 dBm.

The level of the signal at the RX/IF output is a factor of input signal level and total
system gain.

The system gain is adjustable by the user over a 25 dB range.

The typical system gain includes a 50 dB LNA, making the total typical system gain 70
to 95 dB.

Note: A 60 dB LNA is only used when there are extremely long cables from the LNA to
the down converter.

2.5.4 RX/RF Input (J4)

The RX/RF input is a type N connector that comes from the LNA. The input impedance
is 50

. The connector also has the LNA DC power on the center conductor.


The input frequency range depends upon receive band options, either:

• Full 10.95 to 12.75 GHz band
• Individual

sub-band:

Š 10.95 to 11.7 GHz
Š 11.7 to 12.2 GHz
Š 12.25 to 12.75 GHz

2–20
