Chapter 5. THEORY OF
OPERATION
This chapter provides the basic theory of operation for the following:
• Monitor and Control (M&C)
• High stability oscillator
• IFLO
• Synthesizer
• Up and down converters
5.1 Monitor and Control
The RFT-1200 uses a sophisticated microcontroller module to perform the M&C
functions of the terminal. This board (refer to Figure 5-1) is located inside of the
RFT-1200—on top of the other assemblies.
The M&C monitors the RFT-1200 and provides configuration updates to other modules
within the terminal when necessary.
Terminal configuration parameters are maintained in EEPROM, which provides for total
recovery after a power-down situation.
Fault monitoring and status gathering is also provided.
All RFT-1200 functions are accessible through the local front panel keypad/display or a
remote communications interface.
Note: For more information on the M&C board, refer to Section 1.1.2.
5–1
