KST-12000 Ku-Band Satellite Terminal Revision 4
Operation MN/KST12000.IOM
4.2 Remote Control
Refer to Appendix A.
4.3 Front Panel Display/Keypad
The optional front panel (Figure 4-1) provides the local user interface, which is necessary
to configure and monitor status of the satellite terminal.
Figure 4-1. RFT-1200 Terminal Keypad
The front panel features a 16-character, 2-line LCD display, and a 6-key keypad which
provides for sophisticated functions, yet is easy to use. All functions are accessible at the
front panel by entering one of three predefined “SELECT” categories or levels:
• Configuration (CONFIG)
• Monitor
• Faults
4–2
