DFI CR101-D - Manual (Page 9)

www.dfi .com
9
Chapter 2 Hardware Installation
Chapter 2
Chapter 2 - Hardware Installation
Board Layout
DVI-I
HDMI
COM1
1
Chassis intrusion
COM2
1
2
1
COM2 RS232/422/485
Power Select (JP13)
2 10
9
6
5 COM2 RS232 Power
Select(JP14)
1
2
5
6
1
Peripheral Power
System Fan2
1
Front Panel
1 2
11 12
+12V Power
COM1 RS232
Power Select
(JP1)
1
2
5
6
COM1 RS232/422/485
Power Select (JP4)
1 5
Power-on Select
(JP12)
1
6 2
CPU Fan
1
2
ON
1 SW1
1
USB 0-1/2-3 Power Select
(JP6)
1
8
LCD/ Inverter
power
Backlight Levle
Stlect (JP11)
1
1 2
40 39
LVDS LCD panel
PCIe x16
Panel Power
Select (JP9)
1 2
5 6
SPI Flash BIOS
Front Audio
1 2
9 10
S/PDIF
1
SATA 0
SATA 1
SATA 2
SATA 3
SATA 2.0
2
2
1
Socket G2
rPGA-988B
DDR3_2 SODIMM
DDR3_1 SODIMM
DC-IN
Mini PCIe
1
Clear CMOS (JP10)
Standby Power LED 1
1
1
USB 6-7
USB 4-5
10
10
Battery
LAN 1
USB 1
USB 0
Line-out
Mic-in
Line-in
Buzzer
SATA 3.0
USB 4-5/ 6-7
Power Select(JP7)
ASM1442
LPC
1
2 10
9
Intel
HM76
System Fan1
1
4 2
3
LAN 2
USB 3
USB 2
System Memory
DDR3-2
DDR3-1
Standby
Power LED
Features
• Two 204-pin DDR3 SODIMM sockets
• Supports 1066/1333/1600MHz DDR3 SDRAM
• Dual channel memory interface
• Supports maximum of 16GB system memory
Important:
Electrostatic discharge (ESD) can damage your board, processor, disk drives, add-in
boards, and other components. Perform installation procedures at an ESD workstation
only. If such a station is not available, you can provide some ESD protection by wear-
ing an antistatic wrist strap and attaching it to a metal part of the system chassis. If
a wrist strap is unavailable, establish and maintain contact with the system chassis
throughout any procedures requiring ESD protection.
Important:
When the Standby Power LED lit red, it indicates that there is power on the system
board. Power-off the PC then unplug the power cord prior to installing any devices.
Failure to do so will cause severe damage to the motherboard and components.
