CPU Smart Fan Control
When this feature is set to Automatic, the CPU’s fan speed will rotate according to the
CPU’s temperature. The higher the temperature, the faster the speed of rotation.
System Smart Fan Control
When this feature is set to Automatic, the System’s fan speed will rotate according to
the System’s temperature. The higher the temperature, the faster the speed of rota-
tion.
Boundary 1 to Boundary 4
The range is 0-127.
Speed Count 1 to Speed Count 5
The range is 1-100%.
Case Open
Sets this field to Enabled to allow the system to alert you of a chassis intrusion event.
Second Super IO Configuration
This section is used to set parameters for the system second super IO chip.
Set Parameters of Serial
Port 6.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Second Super IO Confi guration
Second Super IO Chip
Serial Port 6 Confi guration
Serial Port 7 Confi guration
Serial Port 8 Confi guration
Serial Port 9 Confi guration
Advanced
NCT5104D
Select Screen
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save & Reset
ESC: Exit
Serial Port 6 Configuration to Serial Port 9 Configuration
Sets parameters
of serial port 6 to serial port 9.
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Serial Port 6 Confi guration
Serial Port
Device Settings
Change Settings
Advanced
[Enabled]
IO=240h; IRQ=5;
[Auto]
Select Screen
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save and Reset
ESC: Exit
