26 DR ® RAPIDFIRE™ LOG SPLITTER
Parts List – DRIVE ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 29461 Flywheel, Spoke Design
2 27574 Engine, Subaru, 6hp, 50state, E/S, W/
Labels
3 29487 Boot, Terminal, Red
4 33331 Nut, Nylon Lock, Flanged, 1/4-20
5 29494 Key, Square, 3/8" X 3/8" X 1.5" L
6 29493 Screw, Set, Cup Point, 3/8 X 16 X .5 L
7 29454 Gear, Pinion
8 27575 Key, Square, 3/16" X 3/16" - 1/2"
9 16514 Washer, .385" ID, 1.39" OD, .15" T
10 11243 Washer, Lock, Split, 5/16"
11 17882 Bolt, HCS, 5/16-24 x 1", GR2 ZP
12 29455 Housing, Bearing
13 29456 Insert Bearing W/ Snap Ring
14 31356 Mount, Engine
15 32111 Bearing, 6301, 12mm ID, 37mm OD,
12mm W
16 32107 Ram
17 29459 Gear, Rack
18 29468 Spring, Compression, Carriage
19 32099 Bracket, Rack, Lifter
20 32114 Pulley, 2 Groove, 4l, 3/4" Keyway
Ref# Part# Description
21 33356 Belt, 4l700
22 29498 Cylinder, Bumper
23 32126 Bracket, Return, Stop
24 32122 Washer, 5/16" ID, 2.0" OD, 0.13" T
25 12336 Bolt, HHCS, 5/16-18 X 1.25", GR.5, ZP
26 11238 Washer, Flat, 1/4", USS
27 33358 Bolt, Hex, Flange, M12-1.75 x 50, CL 8.8,
ZP
28 31238 Bolt, HCS, 1/2-20 X 2.5", GR8, ZP
29 23499 Washer, SAE Flat, 1/2", ZP
30 33351 Bolt, Hex, Flange, 3/8-16 X 1.25"
31 33352 Bolt, Hex, Flange, 5/16-18 X 1.5"
32 33332 Nut, Nylon Lock, Flanged, 5/16-18
33 33333 Nut, Nylon Lock, Flanged, 3/8-16
34 18755 Nut, Nylon Lock, 5/16-18, LP
35 13443 Bolt, HCS, 5/16-18 X 1-1/2", GR5, ZP
36 11242 Washer, Lock, 0.5"
37 30253 Nut, Nylon Lock, M12-1.75
38 33354 Bolt, HCS, M12-1.75 x 30, CL 8.8, ZP
39 33346 Bushing, Bronze, 0.5" ID, 0.625" OD,
0.375" L
40 11152 Bolt, HHCS, .375-16 X 1.00" Lg.
