P UB . 42004-441G
H ANDS - FREE V O IP T ELEPHONES P AGE 22 of 24
e:\standard ioms - current release\42004 instr. manuals\42004-441g.doc
02/15
Specifications
Power
Network power.............................................................. Power-over-Ethernet, 802.3af compliant (via RJ45)
Local power requirements .............................................................................................. 24–48 V dc, 6 watts
Network ............................................................................ 10/100 BaseT Ethernet RJ45, Cat5 or Cat5e UTP
Static IP Provisioning or DHCP STUN client (NAT traversal)
Call control signaling ...................................................................... SIP (RFC3261 compliant) loose routing
Configuration ............................................................................................................... Embedded web server
Configuration file download
Direct serial connection
Password protection
Inputs
Keypad (Model 394AL-702 only) .............................................................................................. 3
 4 matrix
Push buttons ...................................................................... Three auto-dial and an off-hook indicator/switch
Configurable inputs (quantity = 4) ............................................................. Internal pull-up 3.3 V dc tolerant
Outputs
Output 1 .............................................................................................. 8 amps @ 30 V ac/dc (resistive load)
Output 2 .............................................................................................. 8 amps @ 30 V ac/dc (resistive load)
Indicators
External .................................................................................................................... Off-hook indicator light
Internal on VoIP PCBA ........................................................................... Power, Heartbeat, & EACT LEDs
Audio output ........................................................................ 85 dB SPL or greater @ 1.0 meters (@ 1 kHz)
Mechanical
Temperature range
Operating
........................................................................................ −4º F to +131º F (−20º C to +55º C)
Storage ............................................................................................. −40º F to 158º F (−40º C to +70º C)
Relative humidity .............................................................................................. Up to 95%, non-condensing
PCBA (printed circuit board assembly) ............................................................................. Conformal coated
Model 393-700
Enclosure construction .............................................................................. Engineered plastic, safety yellow
Dimensions ................................................. 9.50 H
 8.00 W  4.00 D inches (241.3  203.2  101.6 mm)
Weight ................................................................................................................................... 4.0 lbs. (1.8 kg)
Models 393AL-700 and 394AL-702
Enclosure construction ........................................................................ Cast aluminum painted safety yellow
Braille keypad (Model 394AL-702 only) ................................................................. Chrome-plated zinc
Dimensions ................................................. 9.50 H  8.00 W  4.00 D inches (241.3  203.2  101.6 mm)
Weight
Model 393AL-700 .......................................................................................................... 7.8 lbs. (3.5 kg)
Model 394AL-702 .......................................................................................................... 8.5 lbs. (3.8 kg)
