Pub. 42004-464B
Model 10458-701 and 10458-801 VoIP & VoIP WiFi Electronic Paging Modules Page 11 of 24
f:\standard ioms - current release\42004 instr. manuals\42004-464b.doc
07/14
WiFi Module (Model 10458-801 only)
Antenna (part of Model 12234-102 Antenna Lens Kit, purchased separately) .................. 2.4 GHz, 2.0 dBi,
50-ohm,
omni-directional,
¼ wavelength dipole configuration, VSWR <2.0
Standards .............................................................................................................. Wireless 802.11b, 802.11g
Static IP provisioning or DHCP STUN client (NAT traversal)
Frequency ............................................................................................................... Europe 2.412–2.472 GHz
USA 2.412–2.462 GHz
Antenna connector ................................................................................................................................. BNC
Mechanical
Physical dimensions ................................... 4.50 W
 7.00 D  7.63 H inches; (114.3  177.8  193.8 mm)
Enclosure material ...................................................................................................... 0.062 thick aluminum
Connections......................................................................................................... Screw type terminal blocks
Shipping weights
Model 10458-701 ................................................................................................................. 4.5 lbs. (2.04 kg)
Model 10458-801 ................................................................................................................. 5.0 lbs. (2.27 kg)
Environmental
Temperature range ................................................................................. −4º F to +140º F (−20º C to +60º C)
Humidity ............................................................................................................ Up to 95%, non-condensing
Approval Standards
USA .............................................................. FCC Modular Approval, FCC ID: FCC ID: XM5-SM2144N1
CFR Title 47 FCC Part 15, Subpart B and C
Canada ............................................................... Industry Canada Module Approval IC: 8516A-SM2144N2
Industry Canada ICES-003, RSS-Gen, RSS-210
EU ............................................................................................. EN 300 328 (R&TTE Directive 1999/5/EC)
EN 301 489 (EMC Directive 2004/108/EC)
