Hoist Fitness V HI-LO - Manual (Page 11)

2
3
GUARD BOLT
GUARD ROD
GUARD ROD
FRAME ASSEMBLY
NOTE:
- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.
CABLING PROFILE VIEW
OWNER'S MANUAL
V HI-LO OPTION ASSEMBLY PAGE 10
NOTE:
BE SURE CABLE (3) IS
POSITION BETWEEN
PULLEY AND GUARD
ROD.
NOTE:
BE SURE CABLE (3) IS
POSITION BETWEEN
PULLEY AND GUARD
ROD.
NOTE:
BE SURE CABLE (3) IS
POSITION BETWEEN
PULLEY AND GUARD
BOLT.
