HAND TIGHTENED HARDWARE.
REUSE EXISTING HARDWARE.
- WRENCH TIGHTEN ALL PREVIOUSLY
FRAME ASSEMBLY
NOTE:
- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.
- INSTALL CABLE AND PULLEYS AT THE
SAME TIME.
- WRENCH TIGHTEN HARDWARE (BOLT)
TO SECURE (PULLEY).
*
IT WILL BE NECESSARY TO LOOSEN SOME FRAME HARDWARE TO RE-ALIGN THE
*IMPORTANT*
OWNER'S MANUAL
V HI-LO OPTION ASSEMBLY
ASSURE THAT YOUR UNIT IS ASSEMBLED SQUARE AND PERPENDICULAR. IF NOT,
PAGE 36
NOW THAT THE V HI-LO OPTION IS COMPLETELY ASSEMBLED TAKE TIME TO
FRAME AND RETIGHTEN BOLTS.
CABLE GUARD BOLT
*
*
1
*
(CABLE GUARD BOLT)
BE SURE CABLE (1) IS
POSITIONED BETWEEN
(PULLEY) AND
*
PULLEY
PULLEY
GUARD BOLT
1
