ITEM NO. PART NUMBER DESCRIPTION QTY
36 026-01PL2418 BUSHING: FLANGED 2.28" OD X 2.03" ID X 1.00" LG. 2
37 026-01PL2427 VINYL SLEEVE .50" OD X .38" ID 1
38 013-0002003 1/4" X 16mm SAE FLAT WASHER (WZ) 6
39 013-0302008 5/16" SAE FLAT WASHER (WZ) 1
40 013-0402007 3/8" X 22mm FLAT WASHER (WZ) 29
41 013-0102003 1/2" X 27mm SAE FLAT WASHER (WZ) 6
42 013-0102022 3/8" INTERNAL LOCK WASHER 2
43 013-0302014 1/2" INTERNAL LOCK WASHER 2
44 011-0102064 1/4"-20UNC x 2.00" FHB (WZ) 6
45 011-0101026 3/8"-16UNC X 1.00" BHCS (WZ) 1
46 011-0101034 3/8"-16UNC X 1.25" BHCS (WZ) 1
47 011-0407027 3/8"-16UNC X 1.75" HHB (WZ) 4
48 011-0107026 3/8"-16UNC X 2.25" HHB (WZ) 2
49 011-0407026 3/8"-16UNC X 3.00" HHB (WZ) 1
50 011-0107051 3/8"-16UNC X 3.50" HHB (WZ) 1
51 011-0107018 3/8"-16UNC X 3.75" HHB (WZ) 6
52 011-0407043 1/2"-13UNC X 2.25" HHB (WZ) 2
53 011-0107038 1/2"-13UNC X 4.25" HHB (WZ) 2
54 012-0104009 1/4"-20 UNC THIN NYLOCK NUT (WZ) 6
55 012-0104008 3/8"-16 UNC THIN NYLOCK NUT (WZ) 15
56 012-0304011 1/2"-13 UNC THIN NYLOCK NUT (WZ) 2
57 021-0003230 DECAL HOIST 1.63" X 5.93" 1
58 021-0003426 DECAL PULL 1
59 021-0003680 DECAL DO NOT USE HANDLE AS STEP 1
60 SERIAL # DECAL DECAL HOIST SERIAL # 1.63" X 2.63" 1
61 011-0007050 3/8"-16UNC X 2.75" HHB (WZ) 1
62 020-0014033 ADJUSTER TUBE LUBRICATION KIT 1
PART LIST CONTINUED
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
OWNER'S MANUAL
PAGE 42 V HI-LO OPTION ASSEMBLY
