PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
PAGE 41
OWNER'S MANUAL
V HI-LO OPTION ASSEMBLY
ITEM NO. PART NUMBER DESCRIPTION QTY
1 010-01C0378 CABLE ASSEMBLY: V HI-LO AB 167.91" LG. 1
2 010-01C0379A CABLE ASSEMBLY: V HI-LO COUNTER WEIGHT 74.75" LG. 1
3 010-01C0380 CABLE ASSEMBLY: V HI-LO SWIVEL 311.30" LG. 1
4 026-01X5019 SWIVEL PULLEY HOUSING ASSEMBLY 1
5 026-01X5067 ADJUST LEVER ASSEMBLY 1
6 026-01X5069 HI-LO ADJUSTER ASSEMBLY 1
7 026-01X5082 HI-LO TOP MOUNT ASSEMBLY 1
8 026-01X5087 BASE ASSEMBLY 1
9 026-01X5091 GUIDE TUBE ASSEMBLY 1
10 026-01X5093 TOP HEAD ASSEMBLY 1
11 026-01X5102 ADJUSTER TUBE ASSEMBLY 1
12 013-0602002 3/8" FLAT NYLON WASHER 1
13 014-0003003 BEARING: FLANGED BALL BEARING .50" I.D. 2
14 014-0012012 BEARING: BALL BEARING, .39" I.D. 1
15 014-0015026 E-CLIP .31" 1
16 015-0003006 RUBBER O-RING: 5/16" ID X 1/2" OD 2
17 014-0101002 BUSHING: OILITE FLANGED Ø.75 O.D X Ø.50 I.D X .38 LG. 2
18 016-0201004 END CAP 1.50" X 1.50" (BLACK) 1
19 018-0001001 PULLEY: 2" BLACK W/ CONV. GRADE BEARINGS 1
20 018-0001002 CABLE PULLEY: 3.50" 7
21 018-0002015 CABLE PULLEY: WIDE (BORED HUB) 3.50" 2
22 020-0011009 SPRING 1
23 026-01M0128-1 PULL PIN CAP 1
24 026-01M2343 COUNTER WIEGHT RING 2
25 026-01M2536 COUNTERWEIGHT (4.35 LB) 1
26 026-01M2555 HEAVY FLANGED SHOULDERED SPACER .86"OD X .39"ID 2
27 026-01M2561 QUICK RELEASE CABLE LOCK Ø.34" ID 1
28 026-01M2562A QUICK RELEASE CABLE LOCK - 1/8" CABLE 1
29 026-01M2564-3 PULL PIN: SHORT TAPERED END 1
30 026-01P1439 DUAL PULLEY SHIELD 2
31 026-01P6125 CHANNEL: 1.00" X 1.47" X 72.00" LG. 1
32 026-01PL0206-27 GRIP OPEN END 1.00" ID X 7.00" LG. 1
33 026-01PL2154 PLASTIC KNOB: BASE 1.00" ID 1
34 026-01PL2155 PLASTIC KNOB: CAP 1.00" ID 1
35 026-01PL2417 PLASTIC STOP: 1.25" OD X 1.25" LG. 2
