Hoist Fitness V HI-LO - Manual (Page 26)

40
55
3
20
8
BOLT
(50) AS SHOWN
50
PULLEY
BE SURE TO POSITION
CABLE (3) BETWEEN
PULLEY (20) AND BOLT
40
FRAME ASSEMBLY
NOTE:
- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.
- FEED CABLE (3) BETWEEN PULLEY
(20) & BOLT (50).
- MAKE SURE (3) IS PROPERLY
ALIGNED WITH (20).
PAGE 25
OWNER'S MANUAL
V HI-LO OPTION ASSEMBLY
