5-4 Service Manual
P
ARTS
L
IST
- 200/230/400V
POWER SUPPLY - 200/230/400V
Top and Right Side
Index No. Part No. Description Ref. Desig. Quantity
1 003078 Relay:30A NO Mag Blwt QDisc Term CR2 1
2 029674 MOV/Cap Assy:MAX42/43/70 3PH MOV1 1
029957 Heatsink SA:Powermax800/900 Power Unit 1
3 029998 IGBT Gate Drive SA:Powermax800/900 Q1 1
4 029998 IGBT Gate Drive SA:Powermax800/900 Q2 1
5 109018 Diode:600V 100A UFast Recovery Dual D2 1
6 109018 Diode:600V 100A UFast Recovery Dual D3 1
7 109019 Diode:1600V 100A 3PH Module D1 1
8 041668 PCB Assy:Pwrmx900 Micro Control 1
9 041532 PCB Assy:Powermax800/900-ZB Power 1
10 014137 Current Sense Transformer, 40A CS1 1
11 014137 Current Sense Transformer, 40A CS2 1
12 008958 Fuse:1A 500V 10mmX38mm Slo F1,F2 2
13 029978* Heatsink SA:Powermax800/900 PA Cont PCB Q3
14 041486* PCB Assy:Powermax800/900 PA Cont
128242** Kit:Powermax900 Machine Interface 200/230/400V
15 041494** PCB Assy:Powermax800/900 Machine Interface
Notes: Bold part numbers and descriptions are subassemblies.
Indented normal type items are components of subassemblies.
All mounting hardware in power supply drawings shown for reference only.
* Available only on power supplies with the pilot arc control option
** Available only on power supplies with the machine interface option
See also Section 4 Parts List - 208/240/480V, and Section 6 Parts List - 400V CE
to identify parts for other Powermax900 power supplies.
9-99
